Brief DescriptionHigh-Sensitivity GPS and high efficiency AIS communication technology, which can help you manage your vessels by immediate addressing and SOG. Suitable to install on the offshore vessel, lake boat for collision avoidance.
Features
- Transmission range: 10~16 NM
- Operating time: Up to 20 days (reporting interval: 3 min)
- Easy to install, Easy to Track
- Interval Setting: (Every 15,30 Seconds or 1~6 minutes)
- High-quality and high-reliability battery
- Weather-proof and high gain antenna
- Drop-proof and weather-proof housing
- Waterproof: IPX8
AT-102 is a facilitate AIS class B device that is a high-quality and cost-effective Vessel tracker. Install this device, vessel company can monitor, identity and manage their vessels immediately.
AT-102 provides vessel position, battery power, MMSI, SOG, COG, Heading immediately. The owners can manage their vessels and collision avoidance. Dramatically increase the effectiveness and decrease the cost of management.
AT-102 is lightweight and durable. Easy to install, Easy to Track, The full battery status can be operated continue up to 20 days.
Besides, it can be installed on your boat for collision avoidance. (Other vessels can receive the AIS signal by their AIS Transponder.)
Specification
Model: AT-102
Quad Band: 161.975 MHz / 162.025 MHz
Baud Rate: 9600 b/s +50ppm (GMSK)
Bandwidth: 25 kHz
Output Power: 2 W (can be customized)
Transmission Range: 10~16 NM
Antenna: External 1m VHF antenna
GNSS Chipset: ublox
GPS Receiving Channels: 72 channels
Tracking Sensitivity: -160 dbm
Position Accuracy: 2.5 m CEP
Battery: 12.6V 3200 mAh
Battery Type: Rechargeable Li-ion battery
Operating Time: Up to 20 days (reporting interval: 3 min)
I/O port: 5 pin waterproof connector
Size (Main Body): 21 cm x 9.3 cm
Weight (Main Body): 550g
Waterproof: IPX8
Operating Temperature: -10~60 degree Celsius
Storage Temperature: -20~70 degree Celsius
LED Indication
Flashing 1~10 sec (red & green): Battery level 10~100%
Fast Flashing 10 sec (red): Low power warning
Flashing /sec (green): GPS signal searching
Flashing 3 sec (red & green): AIS data transmitting
